UL3443 Air Conditioner Lead Assy 14AWG Irradiated Flexible Xlpvc Insulated Cable Electric Wire
UL3443 air conditioner lead assy 14awg Irradiated Flexible XLPVC Insulated cable ★Rated temperature:105ºC ★Rated voltage
Description
Basic Info
| Model NO. | UL3443 |
| Application | Interal Wiring of Electric |
| Conductor Material | Copper |
| Type | Hook-up Wire |
| Material Shape | Round Wire |
| Conductor Type | Stranded |
| Wire Core Material | Tinned Copper, Bare Copper |
| Certification | CE, ISO, RoHS, CCC |
| Model | UL3343 |
| Brand | Bort |
| Color | White Blue Red Black Yellow |
| Weight | About 1kg/1000FT |
| Rated Voltage | 300V |
| UL Flame Test | UL Vm-1 |
| Current | DC/AC |
| Production Process | Welding |
| Species | Terminal |
| Character | Environmental Protection |
| User | Socket Terminals |
| Factory Management | ISO9001:2015 |
| Transport Package | Coil |
| Trademark | BORT |
| Origin | China |
| HS Code | 8544492900 |
| Production Capacity | 500000km/Per Year |
Product Description
UL3443 air conditioner lead assy 14awg Irradiated Flexible XLPVC Insulated cable
★Rated temperature:105ºC
★Rated voltage:300V
★According to:UL Subject758,UL1581,C22.2
★Stranded,tinned or bare copper conductor 28--20AWG
★XLPVC insulation
★Passes UL VW-1 FT1 flame test
★Uniform insulation thickness of wire to ensure easy stripping and cutting
★For general purpose internal wiring of appliance
| Conductor | Finished product | Maximum Resistance at 20ºC | |||
| AWG | NO.of Cond | Insulation Thick. | Outside Thick. | ||
| No./mm | DIA mm | mm | mm | Ω/mm | |
| 28 | 7/0.127 | 0.38 | 0.27 | 0.92 | 239 |
| 26 | 7/0.16 | 0.48 | 0.27 | 1.02 | 150 |
| 24 | 11/0.16 | 0.61 | 0.27 | 1.15 | 94.2 |
| 22 | 17/0.16 | 0.76 | 0.27 | 1.30 | 59.4 |
| 20 | 26/0.16 | 0.94 | 0.27 | 1.48 | 36.7 |
Q1: Can I get a free sample?A1: We can provide the existing items samples free in freight collected. If there is any special samples requirement, please contact us for more details.
Q2: How could I pay?A2: We prefer T/T or L/C at sight. If you prefer other payment terms, please contact us freely.
Q3: What is your packing way? Can I have the customized package?A3: We have the standard export package. For more details about the customized package, please contact us.
Q4: What is the delivery lead time?A4: It depends on the order quantities. The mass production lead time is about 7-12 days after receipt of the deposit.
Q5: Are you a factory or a trading company?A5: We are a factory. We provide all kinds of OEM/ODM services for clients around the world.
Q6: Where is your main market?A6: We export to the North America, Southeast Asia, Europe, Korea, Japan, and other countries.Our Services1. Professional QC and QA team to make sure all products qualified before shipping.2. Competitive price
3 .Standard package to ensure the safe transportation.
4. Professional serviceWhy choose us1. Production Qualified production, competitive price, professional service.
2. Technology Professional R& D team3. Equipment With completive testing equipment.
4. Quality UL/ CE/ FCC/ RoHS/ Reach certificate
